ASA Synthetic Resin Tile
The ASA Synthetic Resin Tile offers high durability and excellent weather resistance, ideal for long-lasting roofing solutions.
Product Details
ASA synthetic resin tiles adopt advanced three-layer common pressuretechnology, surface material A: weather-resistant resin; Middle material layerC:PVC material; Bottom material layer B: sub – weathering layer and white ductile wear – resistant material. The raw materials used are brand-new materials provided by high quality company.
Performance of resin tile products
- Strong weather resistance
The ASA layer has excellent UV resistance and corrosion resistance, and is not easily faded or aged when ex posed to outdoor environments for a long time. Its ser vice life can reach 15 years.
- Waterproof and leak proof
The tile design adopts a wave or antique structure, with tight overlapping and smooth drainage, effectively preventing leakage.
- Lightweight and high-strength
The weight is only 1/6 of traditional clay tiles, reducing roof load, but with strong impact resistance and bearing capacity.
- Thermal insulation and sound insulation
Resin material has low thermal conductivity, which can effectively insulate and reduce noise, and improve in door environment.
- Environmental protection and energy conservation
It does not contain harmful substances such as asbestos, can be recycled, and has low energy consumptionduring the production process.
- Easy installation
It can be directly laid on the original roof or wooden structure, with simple construction and saving labor costs.
Product application:
Synthetic resin tiles are widely used in public and civil buildings, villas, row houses, pavilions,clubsHotels, resorts and other buildings,flat slope renovation projects, rural transformation,new rural construction, etc.
Specofocations
| Thickness (mm) | Width (mm) | Length (mm) | Wave Distance (mm) | Wave Height (mm) | Pitch (mm) |
|---|---|---|---|---|---|
| 2.8 | 1050 | Length | 160 | 30 | 219 |
Main tiles and accessories
Resin tiles are divided into natural resin tiles and synthetic resin tiles. The resin tiles commonly referred to in the market are generally synthetic resin tiles. Synthetic resin tiles are made using high-weatherability engineering resin ASA developed by SABIC, a Fortune 500 company. The effective width is within 1.5 meters. ASA is a copolymer of acrylonitrile (Acrylonitrile), styrene (Styrene), and acrylic rubber (Acrylate)…
Main Tile
Use：Roofing
Top Ridge Tile
Use：For Main Roof
Tilted Ridge Tile
Use：For Tilted Roof
End cap of top ridge tile
Use：End cap of main ridge tile
End cap of side ridge tile
Use：End cap of tilted roof
2 side ridge connector
Use：Ridge:for connection
3 side ridge connector
Use：Ridge:for connection
4 side ridge connector
Use：Ridge:for connection
Left Right eave board
Use：Dormer clapboard
Drain board
Use：Eaves flashing board
J seal eave
Use：Dormer clapboard
Gable flashing board
Use：Wall sealing tile
Vertical wall flashing board
Use：Water draining tile
Antique draining board
Use：Water draining tile
90° sealing plate
Use：Wall sealing tile
135° inside corner board
Use：Dormant window gutter flashing
Top Ridge Tile
Use：For Main Roof
Tilted Ridge Tile
Use：For Tilted Roof
Left Right eave board
Use：Dormer clapboard
End cap of side ridge tile
Use：End cap of tilted roof
End cap of top ridge tile
Use：End cap of main ridge tile
3 side ridge connector
Use：Ridge:for connection
Top Ridge Tile
Use：For Main Roof
Additional information
| color |
GZ Red ,Gary ,Claret ,Blue ,Blue Ash ,Birck Red |
|---|
